Vertical Touch Screen TFT Monitor 720x1280 LCD Capacitive Display 3.46 Inch

Brand Name : RGH

Model Number : RTP35HD010A

Place of Origin : Shenzhern,China

MOQ : 3PCS

Price : Negotiable

Certification : ISO9001/ISO14001

Payment Terms : L/C, T/T,Paypal

Supply Ability : 3.5kk

Delivery Time : 3-5weeks

Packaging Details : Standard Exportation Package

Screen Size : 3.5 inches

Resolution : 720*1280

Brightness : 380 cd/m²

Interface : MIPI

Touchscreen : YES

Viewing Angle : ALL

Display Type : Thin Film Transistor Liquid Crystal Display

Backlight Type : LED

Contact Now

Vertical Touch Screen TFT Monitor 720x1280 LCD Capacitive Display 3.46 Inch

NO.	Symbol	Level	Function
1	A		LED power anode
2	A		LED power anode
3	K		LED power cathode
4	K		LED power cathode
5	VCI		Power setting
6	RESET		RESET PIN
7	GND		Ground
8	IOvCC		Power supply for digital interface
9	GND		Ground
10	D1P		MIPI Data pin Positive
11	D1N		MIPI Data pin Positive
12	GND		Ground
13	CLKP		Mipi clock signal
14	CLKN		Mipi clock signal
15	GND		Ground
16	D0P		MIPI Data pin Positive
17	D0N		MIPI Data pin Positive
18	GND		Ground
19	D2P		MIPI Data pin Positive
20	D2N		MIPI Data pin Positive

Vertical Touch Screen TFT Monitor 720x1280 LCD Capacitive Display 3.46 Inch

FAQ

1: What are the payment terms?
A: We usually accept T/T, Paypal, other terms to be negotiated.

2: What’s the lead time?
A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).

3. Do you support custom logo on the LCM?

A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.

4. How can I place a sample order?

A: Pls send us your inquiry, our sales will contact you soon.

5. What size LCD display can you provide?

A: 0.96 inch to 21.5 inch TFT LCD display we can provide.

7. What's your MOQ?

A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.

8. What shipping ways do you support?

A: We can consult with it.
