1.5 Inch TFT LCD Display with 480*240 Resolution LED Backlight Type High Brightness 160cd/m2

Product Categories
Rongguang Hui Optoelectronics Science and Technology
Contact Now

1.5 Inch TFT LCD Display with 480*240 Resolution LED Backlight Type High Brightness 160cd/m2

Brand Name : RGH

Model Number : RT15WH010J

Certification : ISO9001/ISO14001

Place of Origin : Shenzhern,China

MOQ : 3PCS

Price : Negotiable

Payment Terms : L/C, T/T,Paypal

Supply Ability : 3.5kk

Delivery Time : 3-5weeks

Packaging Details : Standard Exportation Package

Screen Size : 1.5 inch

Resolution : 480*240

Dimensions : 37.10(W)*32.7(H)*2.50

Interface : RGB 8BIT

Backlight Type : LED

Viewing Angle : 6 O'CLOCK

Display Technology : Thin Film Transistor (TFT)

Brightness : 160cd/m²

Active area : 29.76(W) X22.32 (H) mm

Operating temperature : -10℃~60℃

Storage temperature : -20℃~70℃

Driving IC : OTA5182A

Response time : 35ms

Contact Now

1.5 Inch TFT LCD Display with 480*240 Resolution LED Backlight Type High Brightness 160cd/m21.5 Inch TFT LCD Display with 480*240 Resolution LED Backlight Type High Brightness 160cd/m2

Item Specification

Size

 1.5 inch

Display mode
Transmissive TFT

Part NO.
RT15WH010J

Resolution

 480*240

Outline size
37.10 (W) X32.70(H) X2.50 mm

Active area
29.76(W) X22.32 (H) mm

View direction
6 o’clock

Piexl pitch
480(RGB)X 240

Interface

 RGB 8BIT

Backlight

 2LEDS

Surface luminance

 160cd/m2

Logic voltage

 2.5v-3.3v

Operating temperature
-10℃~60℃

Storage temperature
-20℃~70℃

1.5 Inch TFT LCD Display with 480*240 Resolution LED Backlight Type High Brightness 160cd/m2

1.5 Inch TFT LCD Display with 480*240 Resolution LED Backlight Type High Brightness 160cd/m2

1.5 Inch TFT LCD Display with 480*240 Resolution LED Backlight Type High Brightness 160cd/m2 1.5 Inch TFT LCD Display with 480*240 Resolution LED Backlight Type High Brightness 160cd/m2

1.5 Inch TFT LCD Display with 480*240 Resolution LED Backlight Type High Brightness 160cd/m2

1.5 Inch TFT LCD Display with 480*240 Resolution LED Backlight Type High Brightness 160cd/m21.5 Inch TFT LCD Display with 480*240 Resolution LED Backlight Type High Brightness 160cd/m2

1.5 Inch TFT LCD Display with 480*240 Resolution LED Backlight Type High Brightness 160cd/m2

1.5 Inch TFT LCD Display with 480*240 Resolution LED Backlight Type High Brightness 160cd/m2

Custom LCD FAQ

1. Are you a factory or a trading company?

we are a high-tech manufacturer specializing in the R&D, production, and sales of LCD and LCM since 2011. At present, we have two factories in Dongguan.


2.What are our main products?

Providing One-stop Liquid Crystal Display and LCM Series, such as COG, COB, ) Customized LCD Series, including Touch Panels


3.What kind of certification do we have?

Our factories have passed ISO9001, 14001 and other certifications.

4. What size LCD display can you provide?

0.96 inch to 21.5 inch TFT LCD display we can provide.
